Hydraulic check block check valve VBPDE | 1/4 | 20L/min | 350 bar VRDE 1/4

22.00

SKU: VRDE G1/4 Category:

Description

Hydraulic check block check valve VBPDE | 1/4 | 20L/min | 350 bar VRDE 1/4

Technical specifications:

Internal thread in body: 1/4” [BSP]

Flow rate: 20L/min

Max. working pressure: 350bar

Liquid temperature: -15 C … +80 C

Material: galvanized steel

Number of hydraulic holes in the body: 4

Flow lock opening pressure: 4 bar

Weight: 0.6kg

Temperature range and oil type:

Permissible ambient temperature: -40 C to +60 C

Permissible oil temperature: -15 C to +80 C

Oil type: Mineral oil based hydraulic oil

Additional information

Weight0.5 kg
